Overview
| Model NO. | LSZH Aluminum | Application | Power Station, Power Distribution, Underground, Photovoltaic Power, Industrial |
| Voltage | LOW Voltage | Conductor | Aluminum |
| Insulation Material | XLPE | Jacket | LSZH |
| Material Shape | Round | Temperature | -40°C ~ +90°C |
| Certification | ISO, CCC, CE, RoHS, VDE | Conductor Type | Compact Stranded |
| Brand | ZhongYI | Voltage Type | 0.6/1 kV |
| Company Name | ZHONGYI Cable Co., Ltd | CORE | 2-120 |
| Transport Package | Plastic Packaging and Cardboard Boxes | Specification | 10 – 630 mm² |
| Origin | HEBEI China | Color | Black |
LSZH Aluminum Cable Core Technical Specifications & Data Sheet
| Nominal area of conductor | Approx. conductor diameter | C.S | XLPE | I.S | Approx. metallic screen tape thickness | Approx. overall diameter | Approx. overall weight |
|---|---|---|---|---|---|---|---|
| 35 | 6.9 | 0.3 | 5.5 | 0.3 | 0.076 | 0.5 | 1135 |
| 50 | 8.1 | 0.3 | 5.5 | 0.3 | 0.076 | 0.5 | 1300 |
| 70 | 9.7 | 0.3 | 5.5 | 0.3 | 0.076 | 0.5 | 1568 |
| 95 | 11.3 | 0.3 | 5.5 | 0.3 | 0.076 | 0.5 | 1861 |
| 120 | 12.6 | 0.3 | 5.5 | 0.3 | 0.076 | 0.5 | 2163 |
| 150 | 14.1 | 0.3 | 5.5 | 0.3 | 0.076 | 0.5 | 2455 |
| 185 | 15.8 | 0.3 | 5.5 | 0.3 | 0.076 | 0.5 | 2897 |
Features
LSZH Aluminum cable is call Low Smoke Zero Halogen Aluminum Cable.Unlike PVC, LSZH won’t produce “acid rain” (HCl gas) when burning，Aluminum is much lighter than copper, making overhead or long-distance installation faster and cheaper.
| Cable Code / Standard | International / Western Technical Name | Conductor Material | Insulation / Jacket Compound | Fire & Toxic Gas Safety Level | Best Installation Environment | Chinese Equivalent (GB/T) |
|---|---|---|---|---|---|---|
| LSZH Aluminum Power Cable | 0.6/1kV XLPE Insulated LSZH Sheathed Aluminum Power Cable | Compact Stranded Aluminum (Al) | XLPE Insulation + LSZH (Low Smoke Zero Halogen) Outer Jacket | Maximum Safety (Zero toxic gas, minimal translucent smoke) | Public commercial subways, airports, hospitals, data center racks, and crowded high-rise complexes. | WDZ-YJLLY / WDZA-YJLLP |
| YJLV Cable | XLPE Insulated PVC Sheathed Aluminum Power Cable | Compact Stranded Aluminum (Al) | XLPE Insulation + Standard PVC Outer Jacket | Low Safety (Releases dense black smoke and toxic HCl gas in fire) | Outdoor cable trenches, industrial plant outdoor zones, and open infrastructure with high air-flow. | YJLV (Standard PVC Sheath) |
| LSZH Copper Cable | 0.6/1kV XLPE Insulated LSZH Sheathed Copper Power Cable | 99.99% Pure Copper (Cu) | XLPE Insulation + LSZH (Low Smoke Zero Halogen) Outer Jacket | Maximum Safety (Zero toxic gas, minimal translucent smoke) | Premium critical emergency loops, marine shipbuilding, and heavily dense urban commercial grids. | WDZ-YJV / H07Z-R (Single Core) |
| N2XH-Al Cable (VDE 0276) |
German Standard Halogen-Free Flame-Retardant Aluminum Power Cable | Class 2 Compact Stranded Aluminum (RE/RM) | XLPE Insulation + Halogen-Free Polymer Compound (HFFR) | Maximum Safety (Strict IEC 60754 & 61034 compliant) | European municipal brickwork embedding, concrete corridors, and public utility layouts. | WDZ-YJLLY (VDE Standard Edition) |
| NA2XRH Cable (BS Standard) |
Aluminum AWA/SWA Armored LSZH Power Cable | Compact Stranded Aluminum (Al) | XLPE + Wire Armor (AWA for 1C, SWA for Multi-core) + LSZH Sheath | Maximum Safety + Heavy Mechanical Crush Protection | UK/Middle East direct underground burial layouts or open industrial walkways where fire containment is priority. | WDZ-YJLLV32 / WDZ-YJLLV42 |
Flame Retardant: High resistance to fire spread, ensuring safety in crowded spaces.
Low Smoke & Non-Toxic: In a fire, it emits minimal smoke and zero halogen gases, preventing acid damage to equipment and protecting human life.
Cost-Effective: Aluminum conductors offer a lightweight and budget-friendly alternative to copper.
Eco-Friendly: Fully compliant with RoHS and environmental safety standards.As Photovoltaic Power and Solar power.
Corrosion Resistant: Special LSZH jacketing protects the aluminum core from environmental degradation.
Application
Public Infrastructure: Subways, airports, hospitals, and shopping malls where fire safety is critical.
Data Centers: Protects sensitive electronic equipment from corrosive halogen gases during fire incidents.
High-Rise Buildings: Ideal for vertical power shafts and emergency lighting circuits.
Industrial Plants: Used in chemical or power plants where safety and cost-efficiency must be balanced.
Certification
Factory
FAQ
1. What unique life-safety and equipment protection benefits does your LSZH Aluminum cable provide?
**Smoke & Toxic Gas Elimination:** Unlike PVC, our LSZH formulation produces minimal, non-toxic smoke during fires, protecting human life and sensitive equipment from corrosive gases.
2. Why is the combination of XLPE insulation and an LSZH jacket ideal for photovoltaic and industrial plants?
**Thermal & Environmental Resilience:** The 90°C rated XLPE insulation combined with a flame-retardant LSZH jacket offers excellent thermal stability (up to 250°C short-circuit) and environmental protection for dense, critical infrastructure.
3. How do EC-grade compact stranded aluminum conductors lower overall project costs?
**Weight & Cost Optimization:** Using Class 2 compact stranded aluminum, these cables are 40-50% lighter than copper, significantly reducing logistics, installation labor, and supporting structure costs.
4. Where is this 0.6/1kV unarmored LSZH aluminum power cable most recommended for deployment?
**Critical Indoor & Public Infrastructure:** Designed for 0.6/1kV, it is ideal for fire-safety-conscious environments like subway systems, airport terminals, and data centers.
5. What manufacturing standards and packaging limits does ZHONGYI CABLE guarantee for bulk orders?
**Rigorous Standards & Engineering Logistics:** Produced according to IEC 60502-1, IEC 60754, and IEC 61034, we supply in durable wooden/steel drums with full certification.
